30" Amana Freestanding Electric Range with Bake Assist Temp in Stainless Steel - YACR4303MMS

Top Features
Large Oven Capacity (4.8 Cu. Ft.)
Large Oven Capacity gives you the space you need to make dinner and dessert at the same time.
Versatile Cooktop
Our Versatile Cooktop with multiple element options provides up to 2,400 watts on the largest burner to help you cook more of your favourites at the same time.
Bake Assist Temps
Bake Assist Temps offer preset temperature settings to make cooking even more convenient. Just select a temperature, press start and let the oven do the rest.
Additional Features
Easy Touch Electronic Controls Plus
Quickly select bake or broil temperatures with these extra-large and easy-to-read Easy Touch Electronic Controls Plus.
Temp Assure™ Cooking System
Temp Assure™ Cooking System distributes heat throughout the entire oven to deliver delicious results.
Extra-Large Oven Window
See and savor. The Extra-Large Oven Window provides a wide view to let you check on food without having to open the oven door.
Storage Drawer
This Storage Drawer comes with plenty of space to put those pots and pans out of sight and out of mind.
Custom Broil
Use the Custom Broil setting to broil in five-degree increments to melt cheese, sear steak or toast those buns with more precision.
SpillSaver™ Upswept Cooktop
Go ahead, spill the beans. The SpillSaver™ Upswept Cooktop comes with raised edges to make cleanup a cinch.
Warm Hold
Use the Custom Broil setting to broil in five-degree increments to melt cheese, sear steak or toast those buns with more precision.
Oven Lockout
Oven Lockout is a safety feature that locks your oven and its controls to help protect against accidental use.
Contemporary Design
With clean lines and modern finishes, our line of free-standing ranges lets you easily choose the features and design details that best fit your budget and lifestyle
Dimensions | |
---|---|
Depth | 27.75 " |
Width | 29.88 " |
Height | 46.88 " |
Carton Depth | 29 " |
Carton Height | 48.75 " |
Carton Width | 32 " |
Depth Closed Excluding Handles | 25.31 " |
Depth Closed Including Handles | 27.75 " |
Depth With Door Open 90 Degree | 46.69 " |
Gross Weight | 152 lbs |
Maximum Height | 47.88 " |
Cutout Depth | 24.0 " |
Cutout Height | 36.0 " |
Cutout Width | 30.0 " |
Capacity FT3 (cubic feet) | 4.80 |
Minimum Height | 46.88 " |
Details | |
Oven Control Type | Electronic Touch |
Bake Element Power | 2400W |
Broiler Element Power | 3400W |
Hidden Bake Element | No |
Oven Interior Depth In Inches | 18.5 |
Oven Interior Width In Inches | 24.5 |
Oven Light Type | Incandescent |
Oven Control Knob Color | Black |
Convection Element Type | None |
Automatic Shut Off | No |
Broiler Location | Top of Oven |
Cooktop Surface Material | Porcelain Coated Steel |
Oven Control Knob Type | Plastic |
Oven Control Location | Rear Control |
Oven Light Switch Location | Oven Control |
Interior Color | Grey |
Number Of Oven Racks | 2 |
Oven Cooking System | Thermal |
Oven Cleaning Type | Manual Clean |
Number Of Rack Guides | 5 |
ELECTRICAL | |
Amps | 40 |
Power Cord Included | Yes |
Certifications | |
UL | Yes |
Energy Rating Kwh Year | 524 |
Appearance | |
Oven Door | Glass |
CONTROLS | |
Electronic Display Type | LED |
Knob Type | Plastic |
Cooktop Details | |
Cooktop Configuration | All Burners |
Left Rear Element Burner Size | 6in. |
Left Rear Element Burner Type | Standard |
Number Of Cooking Element Burners | 4 |
Right Rear Element Burner Type | Standard |
Cooktop Element Style | Coil |
Cooktop Control Type | Knobs |
Cooktop Surface Color | Black |
Cooktop Control Location | Backguard |
Left Front Element Burner Size | 8in. |
Left Front Element Burner Type | Standard |
Right Front Element Burner Size | 6in. |
Right Front Element Burner Type | Standard |
Right Rear Element Burner Size | 8in. |
Left Front Element Burner Power | 2100W |
Left Rear Element Burner Power | 1250W |
Right Front Element Burner Power | 1250W |
Right Rear Element Burner Power | 2100W |
Specifications | |
Dishwasher Safe | No |
Optional Accessories | 4396096RB |
Country Of Origin | USA |
Features | |
Selection | Audible Signal Bake Broil Cancel/Off Clock Control Lock Keep Warm/Warm Hold Sabbath Mode Timer |
Automatic Convection Conversion Temperature Adjust | No |
Hot Surface Indicator Light | Yes |
Power Outage Compatible | No |
Heating Element On Indicator Light | Yes |
Griddle | No |
Exterior | |
Drawer Type | Storage Drawer |
Handle Material | Plastic |
Door Removable | Yes |
Handle Color | Black |
Handle Type | Reach Through Handle |
Description | |
Size In | 30 |
Range Type | Freestanding |
Configuration and Overview | |
Fuel Type | Electric |
