- One-piece front-hinged door with 3 mm precision crafted stainless steel front door panel
- Cushioned door opening and closing system
- Diagonally positioned light sources for optimal interior lighting
- Pyrolytic system
- 17 heating methods, with core temperature probe, rotisserie spit and baking stone function
Additional Information
Heating methods
- Hot air. Eco hot air. Top + bottom heat. Top + 1/3 bottom heat. Top heat. 1/3 top + bottom heat. Bottom heat. Hot air + bottom heat. Hot air + 1/3 bottom heat. Full surface grill + circulated air. Full surface grill. Compact grill. Baking stone function. Roaster function. Dough proofing. Defrosting. Keeping warm.
Handling
- Rotary knob and TFT touch display operation.
- Clear text display.
- Option to save individual recipes (incl. core temperature probe).
- Personalisation of automatic programmes.
- Information key with use indicators.
- Front-hinged door with 90° door opening angle.
Features
- Three-point core temperature probe with automatic shut-off and estimation of cooking time.
- Automatic programmes.
- Rotisserie spit.
- Baking stone socket.
- Actual temperature display.
- Rapid heating.
- Timer functions: cooking time, cooking time end, timer, stopwatch, long-term timer.
- 60 W halogen light on the top.
- 2 x 10 W halogen light on the side.
- Enamelled side shelf supports with 3 tray levels, pyrolysis-safe.
- Home network integration for digital services (Home Connect) either via cable connection LAN (recommended) or wireless via WiFi.
- The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com.
Safety
- Thermally insulated door with quintuple glazing.
- Child lock.
- Safety shut-off.
- Cooled housing with temperature protection.
Cleaning
- Pyrolytic system.
- Gaggenau enamel.
- Heated catalyser to clean the oven air.
Planning notes
- The door panel surface of the appliance extends 40 mm from the furniture cavity.
- The outer edge of the door handle extends 90 mm from the furniture cavity.
- For installation underneath cooktops: Distance between the underside of the cooktop and the top edge of the oven cavity: min. 15 mm. The planning notes for the cooktops (particularly regarding ventilation, gas/electric connection) must be taken into account.
- To achieve the 550 mm installation depth, the connection cable needs to follow the slanted edge on the corner of the housing.
- The mains socket needs to be planned outside the built-in niche.
Connection
- Total connected load 5.9 KW.
- Total Amps: 25 A.
- 208 / 220 - 240 V / 60 Hz.
- Connection cable 1.2 m without plug.
- Power consumption standby/display off 0.5 W.
- Power consumption standby/network 1.5 W.
- Please check the user manual for how to switch off the WiFi module.
