48" Thermador Professional Series Rangetop - PCG486WD
Thermador PROMO Dream Kitchen Sales Event See Details
Dream Kitchen Sales Event
Receive a Bonus gift with the purchase of a complete qualifying kitchen suite.
Literature
You may also like
- LED Downlighting - hidden descretely above the control panel provides functional and stylish illumination
- Patented Pedestal Star® Burner with QuickClean Base® designed for easy surface cleaning and superior heat spread for any size pan
- Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners
- Non-stick, rust-proof cast-aluminum griddle, removable for easy cleanup
INNOVATION
- Exclusive, patented Star® Burner – most even heating, unsurpassed flame coverage
- QuickClean Base® designed for easy surface cleaning
- Precision simmering capabilities as low as 100°F (375 BTU) with 2 ExtraLow® Simmer burners
PERFORMANCE
- Professional style, continuous cast iron grates
- Continuous porcelain, easy to clean cooking surface
- Widest range of simmer options from 375 BTU to 3,000 BTU
- Star® design delivers superior heat spread for any size pan
- Simmer without stirring/scorching with exclusive ExtraLow®
- Superior griddle results-6 pass, 1630 watt electric griddle
DESIGN
- Bold Professional design
- Patented Pedestal Star® Burner with QuickClean Base®
- Restaurant style metal knobs
- Signature blue indicator lighting
- Island trim shipped standard with rangetop
General | |
---|---|
Energy source | Gas |
Type of control | sword knobs |
Safety device | automatic reignition |
Construction type | |
Color of frame | Stainless steel |
Color of surface | Stainless steel |
Installation type | Built-in |
Number of electric elements | 0 |
Number of electric cooking zones | 0 |
Type of frame | Professional, Standard frame |
Number of gas burners | 6 |
Number of halogen elements | 0 |
Installation Type | Built-in |
Type of grate | Cast iron |
Number of radiant elements | 0 |
Number of electric warming zones | 0 |
Size and Weight | |
Overall appliance dimensions (HxWxD) (mm) | 268.3 x 1218 x 656 mm |
Net weight (kg) | 82.438 kg |
Cooking zone 1 | |
Location of 1st heating element | front left |
Type of heating element | Gas |
Cooking zone 2 | |
Type of 2nd heating element | Gas |
Cooking zone 3 | |
Location of 3rd heating element | Rear left to middle |
Type of 3rd heating element | Gas |
Cooking zone 4 | |
Location of 4th heating element | center right |
Power of 4th heating element (W) | 1.63 kW |
Type of 4th heating element | Radiant heating |
Cooking zone 5 | |
Location of 5th heating element | back right |
Type of 5th heating element | Gas |
Cooking zone 6 | |
Location of 6th heating element | front right |
Type of 6th heating element | Gas |
Cooking zone 7 | |
Location of 7th heating element | Front left to middle |
Type of 7th heating element | Gas, Radiant heating |
Cooking zone 8 | |
Location of 8th heating element | front middle / central |
Cooking zone 9 | |
Location of 9th heating element | front centre/cent |
Safety | |
Type of safety device for gas | Without |
Power on indicator | Yes |
Residual heat indicator | without |
Safety device | automatic reignition |
Main on/off switch | - |
Connection | |
Power cord length (cm) | 244 cm |
Energy source | Gas |
Frequency (Hz) | 60 Hz |
Location of gas connection | bottom, rear, right |
Gas connection rating (W) | 31,620 W |
